                               Smc Optic Fiber Distribution Box
It Compliant with ISO 9001:2000, ISO 14001:2001 and TLC certification
Smc Distribution Box:

we are a professional to make Fiber Optic distribution Frame, Integrated Distribution cabinet for more than 20 years with good quality & reasonable price. Now we are the mainly supplier of Telecom, CNC, CUC, CATV in China with 20 provinces.

Specification:
SMC distribution box is suitable for both single and ribbon fiber cable, special suitable for indoor or outdoor optical terminal in optical fiber system & FTTH

Features:
1. Compliant with ISO 9001:2000, ISO 14001:2001 and TLC certification
2. Cabinets are made as the standard of IP65 . It can endure climate changes and adverse environment.
3. Box body is made of SMC(sheet moulding compound)
4. It is the combination of three functions: Optical fusion, store and distribution
5. Adapter is installed with a certain angle. Maintenance is easy and transmission loss is low.

Environment conditions:
Environment temperature:
from -25°C to +40°C
Storage temperature:
from -25°C to +55°C
Air pressure:
70kpa -- 106kpa
Return loss:
FC/PC ≥458DB;FU/UPC≥55DB;FC/APC≥65DB
Mating cycles:
>1000times
Working wavelength:
850nm,1310nm,1550nm

Technical parameters:
Model
Size (H×W×D)
(mm)
Capacity
(core)
Material
MH-MPX.AT.J01
       2600×360×450
    384
SMC(sheet moulding compound)
MH-MPX.FS.A01
       2600×600×300
    100
SMC(sheet moulding compound)
MH-GPX.SM.A01
       2600×520×4500
    384
SMC(sheet moulding compound)
HM-GPX.SM.A02
       2200×520×450
    352
SMC(sheet moulding compound)
HM-GPX.SM.B01
       2600×480×225
    192
SMC(sheet moulding compound)
